| 參數 | 型號 | ||||
| 1810 | 1810 | 1810 | 1820 | 1830 | |
| 量程 | |||||
| 英制 | 1.1K | 2.2K, 3.3K | 5.5K | 11K, 22K | 55K |
| 公制(kN) | 5 | 10, 15 | 25 | 50, 100 | 250 |
| 精度等級—（MAX ERROR） | |||||
| 靜態誤差帶–% FS | ±0.020 | ±0.020 | ±0.020 | ±0.020 | ±0.025 |
| 非線性—%FS | ±0.020 | ±0.020 | ±0.020 | ±0.020 | ±0.020 |
| 滯后性—%FS | ±0.020 | ±0.025 | ±0.025 | ±0.025 | ±0.030 |
| 不可重復性—%RO | ±0.005 | ±0.005 | ±0.005 | ±0.005 | ±0.005 |
| 20分鐘內蠕變—% | ±0.01 | ±0.01 | ±0.01 | ±0.01 | ±0.01 |
| 側向載荷—% | ±0.1 | ±0.1 | ±0.1 | ±0.1 | ±0.1 |
| 偏心載荷—%/in | ±0.05 | ±0.05 | ±0.05 | ±0.05 | ±0.05 |
| 低負載極限t - % Cap. | 2 | 2 | 2 | 2 | 2 |
| (ASTME74 Class A) | |||||
| 溫度 | |||||
| 溫度補償范圍—℃ | -10 to 45 | -10 to 45 | -10 to 45 | -10 to 45 | -10 to 45 |
| 工作溫度—℃ | -55 to 90 | -55 to 90 | -55 to 90 | -55 to 90 | -55 to 90 |
| 零點漂移—%RO/℉—MAX | ±0.0004 | ±0.0004 | ±0.0004 | ±0.0004 | ±0.0004 |
| 靈敏度漂移—%RO/℉—MAX | ±0.0008 | ±0.0008 | ±0.0008 | ±0.0008 | ±0.0008 |
| 電氣特征 | |||||
| 靈敏度輸出—mV/V | 2 | 2 | 2 | 2 | 2 |
| 激勵電壓—VDC MAX | 20 | 20 | 20 | 20 | 20 |
| 輸出電阻—Ohm | 700 | 700 | 700 | 700 | 700 |
| 零點輸出—%RO | ±1.0 | ±1.0 | ±1.0 | ±1.0 | ±1.0 |
| 絕緣電阻—Megohm | 5000 | 5000 | 5000 | 5000 | 5000 |
| 機械特征 | |||||
| 安全超載—%CAP | ±150 | ±300 | ±300 | ±300 | ±300 |
| 撓度 @ RO-inch | 0.002 | 0.002 | 0.002 | 0.002 | 0.004 |
| 重量—kg | 1.72 | 4.05 | 4.05 | 11.25 | 27.9 |
| 標定方式 | 拉力 & 壓力 | 拉力& 壓力 | 拉力 & 壓力 | 拉力 & 壓力 | 拉力 & 壓力 |
| 材質 | 合金鋼 | ||||
